Automatic Filling Machine RB9700

Automatic IVD Filling Machine for Biochemical Reagent is suitable for filling and screwing caps for products such as cell preservation solution, small capacity buffer solution, cleaning solution, and dilution solution. It includes processes such as loading bottles, filling reagent, screwing caps, and labeling. It can be customized according to the customer’s process requirements. More customized features are waiting for you to explore together, Contact Us and leave a message below, thanks!

Find us:

General Specifications:

  1. Pumps option: plunger pump, piston pump, peristaltic pump, syringe pump, etc.
  2. Filling range: 0.5~100ml
  3. Capacity: 1600~1800 bottles/hour
  4. Filling heads qty: 2
  5. Screwing heads qty: 1
  6. Accuracy: 1%
  7. Compress air: 0.5~0.7Mpa
  8. Power supply: 220/110v, 50/60Hz
  9. Powe: 4.5Kw
  10. New weight: 900Kg
  11. Dimension: 2800x2500x2100mm
